Address Cleanse API

Address Cleanse API

Overview

  • The Address Cleanse API is a web service that can be used to perform address validation, deduplication and suppression checks. Flag or make changes to imported data files.
  • It follows RESTful principles – accepting HTTPS requests and returning JSON response documents.
  • See the Address Cleanse API reference for the full interface definition.

Quick Start

  • Register or Login to your Address Cleanse account to get started.
  • Create an Address Cleanse API Token as described in the Authentication section below.
  • To upload a file, a job configuration file must also be supplied. The creation of this is described in the┬áJob Configuration section below.



Authentication / Configuration

Authentication

All Address Cleanse API methods require a security token for authorisation. This token can be generated using the web interface here once logged in.

Simply click vertical ellipsis menu (three vertical dots) in the top right hand corner of the screen to open up a menu. Select Export API Token; a window will appear containing the token text. Store that text for use by your application in all Address Cleanse API service calls.

The token should be sent in a HTTPS header of the format…

Authorization: Bearer $TOKEN_VALUE



Job Configuration

Address Cleanse API job configuration is done via the web interface here once logged in. This only needs to be done once as the same settings can be used for any number of input files, providing the file format and structure remains constant.

Once a job configuration has been created through the UI, it can be exported for use with your client application. A step by step guide of how to user the Address Cleanse UI is availble within the Portal Help Centre

Click on the menu icon in the top right corner and select Export settings for API. A window will appear containing the JSON text describing your settings. Save that text for use by your application, it will be needed by the /api/v1/run method.



Upload a File

There are 3 different methods to be used in uploading a file. This is to allow for the uploading of large files and in avoiding import latency.

Begin

First call the begin method, giving it a size and filePrefix (name).

GET https://www.hopewiser.com/online-address-cleanse/api/v1/files/upload/begin?size=XXX&filePrefix=NAME

Parameters:

NameDescriptionExample Value
sizeThe file size in bytes16384
filePrefixA string that will become part of the filename on the serverCustomerAddresses

Response:

{
  "fileId":"CustomerAddresses1234.dat",
  "chunkUrl":"https://filesvr.hopewiser.com/filesvr/upload/chunk"
}

Chunk

Then call the chunk method using the chunkUrl (in place of the service endpoint used in all other methods here), the fileId returned by /begin and an idx indicating which chunk this is, starting from zero. The file data should be sent in the body of the HTTPS POST request as raw binary data bytes.

PUT https://filesvr.hopewiser.com/filesvr/upload/chunk?fileId=XXX&idx=0
PUT https://filesvr.hopewiser.com/filesvr/upload/chunk?fileId=XXX&idx=1

etc.

Parameters:

NameDescriptionExample Value
fileIdID returned by /beginCustomerAddresses1234
idxIndex number for the chunk0

It is recommended the chunks be no larger than 10 MB; especially if your application is browser based. Call this method repeatedly for each part of the file you upload, incrementing the idx parameter by 1 each time.

End

Once the file data is completely uploaded, call the end method with the fileId returned by /begin, and optionally a hash field containing the sha256 hash of the file. If a hash is provided it will be compared with the file data stored on the server to guarantee the uploaded file’s integrity.

GET https://www.hopewiser.com/online-address-cleanse/api/v1/files/upload/end?fileId=XXX&hash=YYY

Parameters:

NameDescriptionExample Value
fileIdID returned by /beginCustomerAddresses1234
hashSHA256 hash of the file (optional)d785d959746f4180c8c6ef885d9abaccb5a43f004c718a906271c3de014eb69b



Retrieve a list of uploaded files

A list of uploaded files and their metadata can be retrieved using the files method which takes no parameters and returns a JSON array containing a description of each uploaded file. This request returns files that have been processed/run. Those that have only been uploaded, via the proceeding instructions, will not be shown.

GET https://www.hopewiser.com/online-address-cleanse/api/v1/files

Response:

[
  {
    "id": 147,
    "name": "input_address.txt",
    "inputFileServerId": "bureauInput7122032991119785308.dat",
    "cols": 6,
    "rowCount": 597,
    "delimiter": ",",
    "hasHeader": true,
    "useQuotes": false,
    "creationDate": 1510939445,
    "lastUpdate": 1510939445
  }
]

The dates in the response are given using Unix time, which is the number of seconds that have elapsed since January 1, 1970 (midnight UTC/GMT), not counting leap seconds (in ISO 8601: 1970-01-01T00:00:00Z).



Run an Address Cleanse API job

Start a cleanse job

To start a processing run on an uploaded file, call the run method, providing the inputFileId which was returned in the /upload methods, and a name to identify this job. The request body should contain the JSON settings data previously generated from the web interface and exported using Export settings for API in an earlier step.

PUT https://www.hopewiser.com/online-address-cleanse/api/v1/run?inputFileId=CustomerAddresses1234&name=CleanseRun1

Parameters:

NameDescriptionExample Value
inputFileIdID returned by /beginCustomerAddresses1234
nameA name to identify this runCleanseRun1

Body:

{
  "protocol": 2,
  "mafId": 1,
  "inputFileDesc": {
    "cols": 7,
    "delimiter": "|",
    "hasHeader": true,
    "useQuotes": true
  },
  "inputFields": [
  {
    "name": "Add Line 1",
    "mappingId": 6,
    "mappingOrder": 9,
    "inputOrder":14069
  },
  {
    "name": "Add Line 2",
    "mappingId": 6,
    "mappingOrder": 10,
    "inputOrder":14070
  },
  {
    "name": "Add Line 3",
    "mappingId": 6,
    "mappingOrder": 11,
    "inputOrder":14071
  },
  {
    "name": "Add Line 4",
    "mappingId": 6,
    "mappingOrder": 12,
    "inputOrder":14072
  },
  {
    "name": "Add Line 5",
    "mappingId": 6,
    "mappingOrder": 13,
    "inputOrder":14073
  },
  {
    "name": "City",
    "mappingId": 6,
    "mappingOrder": 14,
    "inputOrder":14074
  },
  {
    "name": "Country",
    "mappingId": 0,
    "mappingOrder": 15,
    "inputOrder":14074
  }
  }],
  "outputFields": [{
    "groupId": 1
  },
  {
    "groupId": 8
  },
  {
    "groupId": 2
  },
  {
    "groupId": 3
  },
  {
    "groupId": 4
  }],
  "dedupe": {
    "duplicationLevel": 2,
    "dedupeSeparateFile": false
  },
  "suppress": {
    "suppressDeceased": true,
    "suppressGoneaways": true,
    "suppressPreferenceServices": true
  }
}

Response:

{
  "runId": 49
}

Get the status of a job

Depending on the size of the file and the options selected, the processing run could take only a few seconds or several minutes. To determine the current status of the job you can poll using the status method, giving it the runId returned from /run. This will return a block of JSON text containing the current status of the job. The returned HTTP status code will also change. While the job is running the returned HTTP status will be 404, once the job is complete it will become 200.

GET https://www.hopewiser.com/online-address-cleanse/api/v1/run/status?runId=49

Parameter:

NameDescriptionExample Value
runIdID returned by /run49
{
    "name": "CleanseRun1",
    "statusCode": 6,
    "statusDesc": "Processing",
    "stage": {
        "stageCount": 7,
        "currentStage": 5,
        "stageName": "Post processing",
        "stageStatus": "Postprocess",
        "stageProgress": 0.14285714285714286
    }
}

The stage part of the response will only appear whilst the processing run is in progress. Once the cleanse part of the job is complete the response will only contain the name, statusCode and statusDesc sections.

Possible status codes

ValueDescription
0Uploading
1Uploaded
2QueuedForTest
3ProcessingTest
4FinishedTest
5QueuedForResults
6ProcessingResults
7AwaitingPayment
8Paid
9Error
10Deleted

The number and values of the stages in the stage object are subject to change. The field names are fixed, but their values may be updated.

For example, there are currently 11 stages, but that number may increase or decrease in future. If it does change the stageCount will update to reflect this.



Get results

Once a job is complete various statistics and metadata is available to download. These can be viewed without payment. To download the results file however, it must first be paid for.

All the results methods take as a parameter the runId returned by the run method to identify which job is the one of interest.

Statistics

To obtain details of matches for the various categories of checks made by Address Cleanse (address matches, de-duplications and suppressions), use the statistics method…

GET https://www.hopewiser.com/online-address-cleanse/api/v1/results/statistics?runId=49

Parameter:

NameDescriptionExample Value
runIdID returned by /run49

Body:

{
  "recordCount": integer,
  "codingStats": [
    {
      "name": string,
      "description": string,
      "count": integer
    }
  ],
  "addressUpdateStats": [
    {
      "name": string,
      "description": string,
      "count": integer
    }
  ],
  "dedupeStats": [
    {
      "name": string,
      "description": string,
      "count": integer
    }
  ],
  "suppressionRemovedStats": [
    {
      "name": string,
      "description": string,
      "typeName": string,
      "typeDescription": string,
      "count": integer
    }
  ],
  "suppressionFlaggedStats": [
    {
      "name": string,
      "description": string,
      "typeName": string,
      "typeDescription": string,
      "count": integer
    }
  ],
}

Response:

{
    "recordCount": 76,
    "codingStats": [
        {
            "name": "Matched",
            "description": "A correct address",
            "count": 11
        },
        {
            "name": "UnmatchedPremise",
            "description": "The premise, e.g. house number, was not found",
            "count": 1
        },
        {
            "name": "UnmatchedStreet",
            "description": "The thoroughfare, e.g. street, was not found",
            "count": 1
        },
        {
            "name": "UnmatchedTown",
            "description": "The town was not found",
            "count": 62
        },
        {
            "name": "Unmatched",
            "description": "No parts of the address could be verified",
            "count": 1
        }
    ],
    "dedupeStats": [
        {
            "name": "Unique",
            "description": "The record is unique",
            "count": 98
        },
        {
            "name": "Parent",
            "description": "The first record that is a duplicate based on the level selected",
            "count": 1
        },
        {
            "name": "Child",
            "description": "The record is a duplicate of a parent record",
            "count": 1
        }
    ],
    "suppressionRemovedStats": [
        {
            "name": "Goneaway",
            "description": "People who have moved",
            "typeName": "DBS",
            "typeDescription": "Purifi",
            "count": 11
        },
        {
            "name": "Goneaway",
            "description": "People who have moved",
            "typeName": "DCR",
            "typeDescription": "DisConnect",
            "count": 3
        },
        {
            "name": "Goneaway",
            "description": "People who have moved",
            "typeName": "GAS",
            "typeDescription": "Goneaway Suppression",
            "count": 1
        },
        {
            "name": "Goneaway",
            "description": "People who have moved",
            "typeName": "RMG",
            "typeDescription": "Re-Movers",
            "count": 7
        },
        {
            "name": "Preference",
            "description": "People listed on Mailing Preference Service",
            "typeName": "MPS",
            "typeDescription": "Mailing Preference Service",
            "count": 1
        }
    ],
    "suppressionFlaggedStats": []
}

The name and description for the codingStats may be one of the following;

NameDescription
MatchedA correct address
UnmatchedPremiseThe premise, e.g. house number, was not found
UnmatchedStreetThe thoroughfare, e.g. street, was not found
UnmatchedTownThe town was not found
UnmatchedNo parts of the address could be verified

The name and description for the addressUpdateStats may be one of the following;

NameDescription
RecordCountThe number of records where the address was updated
PostcodeAddedThe number of records where the postcode was not specified in the input but was added to the output
PostcodeUpdatedThe number of records where the postcode was specified in the input but was updated in the output
SubpremiseUpdatedThe number of records where the subpremise was either added or updated to the output
HouseUpdatedThe number of records where the house was either added or updated to the output
StreetUpdatedThe number of records where the street was either added or updated to the output
DistrictUpdatedThe number of records where the district was either added or updated to the output
UnknownUnknown

The name and description for the dedupeStats may be one of the following;

NameDescription
UniqueThe record is unique
ParentThe first record that is a duplicate based on the level selected
ChildThe record is a duplicate of a parent record

The name, description, typeName and typeDescription for both the suppressionRemovedStats and suppressionFlaggedStats may be one of the following;

NameDescriptiontypeNametypeDeccription
DeceasedPeople who have diedMPSMailing Preference Service
DeceasedPeople who have diedMTSMortascreen
DeceasedPeople who have diedNDRNational Deceased Register
DeceasedPeople who have diedTBRBereavement Register
DeceasedPeople who have diedMTLMortaliti
GoneawaysPeople who have movedDBSPurifi
GoneawaysPeople who have movedGASGoneaway Suppression
GoneawaysPeople who have movedRMGRe-movers
GoneawaysPeople who have movedFREFression
Goneaways-ReconnectPeople who have moved, where a forwarding address is availableDBSPurifi
Goneaways-ReconnectPeople who have moved, where a forwarding address is availableGASGoneaway Suppression
Goneaways-ReconnectPeople who have moved, where a forwarding address is availableRMGRe-movers
Preference ServicesPeople listed on Mailing Preference ServiceMPSMailing Preference Service

Costs

To see a breakdown of the various charges incurred for the run, use the costs method…

GET https://www.hopewiser.com/online-address-cleanse/api/v1/results/costs?runId=49

Parameter:

NameDescriptionExample Value
runIdID returned by /run49

Body:

[
  {
    "name": string,
    "cost": integer
  }
]

Response:

[
    {
        "name": "Address Validation",
        "netcost": 3072,
        "cost": 3610
    },
    {
        "name": "De-duplication",
        "netcost": 43,
        "cost": 50
    },
    {
        "name": "Telephone Preference Service",
        "netcost": 7,
        "cost": 8
    },
    {
        "name": "Goneaways",
        "netcost": 299,
        "cost": 351
    },
    {
        "name": "Preference Services",
        "netcost": 1,
        "cost": 1
    }
]

The name may be one of the following;

  • Processing Charge
  • Address Validation
  • De-duplication
  • Telephone Preference Services
  • Deceased
  • Goneaways
  • Preference Services

The cost is in pence, excluding VAT.

Pay

To allow the file to be downloaded use the pay method…

GET https://www.hopewiser.com/online-address-cleanse/api/v1/results/pay?runId=49

Parameter:

NameDescriptionExample Value
runIdID returned by /run49

If you have not set up an agreement with Hopewiser to allow automatic payments, this will return a URL you must manually visit in a browser to complete your payment information.

If you have set up such an agreement then you must still call the pay method, but no further action is needed.

Response:

{
  "invoiceUrl": "https://www.hopewiser.com/payment/xxxx"
}
{
  "invoiceId": "196"
}

Download results file

To retrieve the results (upon completion of payment step), call the file method. This will return a URL from which a zip file containing results and statistics can be downloaded. Please note the “Authorization: Bearer” token is required to authenticate the download URL.

GET https://www.hopewiser.com/online-address-cleanse/api/v1/results/file?runId=49

Parameter:

NameDescriptionExample Value
runIdID returned by /run49

Response:

{
  "downloadUrl": "https://filesvr.hopewiser.com/filesvr/download?downloadName=AddressCleanseResults.zip&fileId=CleanseRun1234.dat"
  "fileServerId": "job-13952588965434633508814.dat",
}

Version

Retrieve the version of Address Cleanse software using the version method…

https://www.hopewiser.com/online-address-cleanse/api/v1/version

Response:

{
    "major": 1,
    "minor": 1,
    "patch": 0,
    "description": "1.1.0"
}
